MSTECH Europe
Classic-STD-460
Shuttle conveyor, 630mm travel length, Dual transfert car; Motorized width adjustment; NG/OK reject functions; PCB Max(mm): 500x460; PCB Min. (mm): 50x50; Machine Size (mm): 1500x650x1250

Application

Shuttle Conveyor /Traverser is used to redirect flow of PCBs into different channels in a production line.It is designed to shuttle PCB's to next process. The conveyor can collect PCB's from two lines to one line/ distribute PCB's from one line to two lines.

Features
• Panasonic PLC +Screen touch panel control;

• Closed loop stepper motor providing the accurate transfer

• Working method:

• 1). distribute the boards from one line into two line.
2). Collect the boards from two line into one line.

• Two working modes are selectable in the software.

• Conveyor width adjustment by motorized and software input automatic width adjustments.

• Shuttle speed setting by software.

• Transfer direction: right to left.

• Cycle time: Depends on traversing distance

• Number of Cart: Sigle head transportation

MSTECH Europe
Classic-CLEANS - 460
PCB surface cleaner conveyor, single side cleaner: PCB size
500mm *460mm ( L*W)


The NEW SMT Clean Machine from MSTECH Europe has been specifically designed to remove contamination from bare boards before solder paste, adhesive application and after laser marking.

The design of the machine will ensure full integration into all SMT lines, providing your process with the best contact cleaning system in the world.

MSTECH Europe
Classic-CLEAND - 460
PCB surface cleaner conveyor, double side cleaner

The NEW SMT Clean Machine from MSTECH Europe has been specifically designed to remove contamination from bare boards before solder paste, adhesive application and after laser marking.

The design of the machine will ensure full integration into all SMT lines, providing your process with the best contact cleaning system in the world.

PCB size
500mm *460mm ( L*W)

MSTECH Europe
Classic-XT-459
Non-contact PCB cleaner

MSTECH Europe
Classic-ICW-460
Infeed conveyor, wave soldering line

Application
Using SMEMA interface, this unit successfully links any machine, this system is special for connection with the wave soldering machine as the infeed conveyor, the conveyor transfer angle is available to adjusted from 4°to 7°by the hand crank wheel.

Features

• Panasonic PLC program control
• Continuous queue feeding PCBs into the wave soldering machine.
• Conveyor width adjustment by using hand crank.
• PCB transfer angle is adjustable
• Heavy bottom design to prevent shifting
• Conveyor motor is using with stepper motor
• Conveyor transfer by chain
• PCB flow direction flows can be customized
• SMEMA compatible

MSTECH Europe
Classic-OCW-460
Outfeed conveyor, wave soldering line

Application :
This unit is special for the unloading conveyors of PCB from the wave soldering machine. The transfer heights are adjustable to meet any kind of wave solder in the market.

Features

• Panasonic PLC program control

• Continuous queue unloading PCBs from the wave soldering machine.

• Conveyor width adjustment by using hand crank.

• PCB transfer angle is adjustable

• Heavy bottom design to prevent shifting

• Conveyor transfer by ESD flat belts or Pin chain conveyor

• PCB flow direction flows can be customized

• SMEMA compatible

MSTECH Europe
Classic MTR-600
The MTR-600 is a high-performance SMT reflow oven designed for precise and reliable lead-free soldering. It combines advanced hot air convection heating with an industrial control system to ensure consistent thermal results and efficient production.
Key Features

12 heating zones (6 top / 6 bottom) + 2 cooling zones
Temperature range: Ambient to 300°C
High accuracy: ±1°C (control), ±1.5°C PCB deviation
Fast warm-up: ~30 minutes
Industrial PC control with profile storage & real-time monitoring
Energy efficient: ~5KW operating consumption
Built-in UPS for power failure protection
MES & LAN connectivity

Conveyor & Capacity

PCB width: 50–460 mm
Speed: 300–2000 mm/min (adjustable)
Chain + mesh conveyor with automatic lubrication
Component height: up to 30 mm (top & bottom)

Cooling & Performance

Forced air cooling, PCB exit ≤ 70°C
Stable heat balance and fast response time (≤20s)

Technical Specs

Dimensions: 4100 × 1430 × 1530 mm
Weight: ~2200 kg
Power supply: 3P 380V / 220V, 50/60Hz
Total power: 48KW

MSTECH Europe
Classic MTR-800
The MTR-800 is a high-capacity SMT reflow oven engineered for precision lead-free soldering and high-throughput production. With extended heating zones and advanced control, it ensures excellent thermal uniformity and process stability.
Key Features

16 heating zones (8 top / 8 bottom) + 6 cooling zones
Temperature range: Ambient to 300°C
High precision: ±1°C control, ±1.5°C PCB deviation
Fast warm-up: ~30 minutes
Industrial PC control with profile storage and monitoring
Energy consumption: ~9KW
UPS, MES & LAN connectivity

Conveyor & Capacity

PCB width: 50–460 mm
Speed: 300–2000 mm/min
Chain + mesh conveyor with automatic lubrication
Component height: up to 30 mm (top & bottom)

Cooling & Performance

3-zone forced air cooling (960 mm)
PCB exit temperature ≤ 70°C
Fast thermal response (≤20s)

Technical Specs

Dimensions: 5520 × 1430 × 1530 mm
Weight: ~2710 kg
Power supply: 3P 380V / 220V, 50/60Hz
Total power: 64KW

MSTECH Europe
Classic MTR-1000
The MTR-1000 is a high-capacity SMT reflow oven designed for demanding production environments, delivering superior thermal uniformity, precision, and throughput for lead-free soldering.
Key Features

20 heating zones (10 top / 10 bottom) + 6 cooling zones
Temperature range: Ambient to 300°C
High precision: ±1°C control, ±1.5°C PCB deviation
Fast warm-up: ~30 minutes
Industrial PC control with profile storage & monitoring
Energy consumption: ~10KW
UPS, MES & LAN connectivity

Conveyor & Capacity

PCB width: 50–460 mm
Speed: 300–2000 mm/min
Chain + mesh conveyor with automatic lubrication
Component height: up to 30 mm (top & bottom)

Cooling & Performance

3-zone forced air cooling (960 mm)
PCB exit temperature ≤ 70°C
Fast heat response (≤20s)

Technical Specs

Dimensions: 6300 × 1430 × 1530 mm
Weight: ~3020 kg
Power supply: 3P 380V, 50/60Hz
Total power: 80KW

MSTECH Europe
Classic MTR-1200
The MTR-1200 is a high-end SMT reflow oven designed for maximum throughput and thermal performance, ideal for complex and high-volume lead-free soldering applications.
Key Features

24 heating zones (12 top / 12 bottom) + 6 cooling zones
Temperature range: Ambient to 300°C
High precision: ±1°C control, ±1.5°C PCB deviation
Fast warm-up: ~30 minutes
Industrial PC control with profile storage & monitoring
Energy consumption: ~13KW
UPS, MES & LAN connectivity

Conveyor & Capacity

PCB width: 50–460 mm
Speed: 300–2000 mm/min
Chain + mesh conveyor with automatic lubrication
Component height: up to 30 mm (top & bottom)

Cooling & Performance

3-zone forced air cooling (960 mm)
PCB exit temperature ≤ 70°C
Fast thermal response (≤20s)

Technical Specs

Dimensions: 7050 × 1430 × 1530 mm
Weight: ~3710 kg
Power supply: 3P 380V / 220V, 50/60Hz
Total power: 96KW

MSTECH Europe
Classic MTX-250
The MTX-250 Vertical Oven is a compact and efficient solution for PCB thermal processing, designed to maximize floor space while ensuring precise temperature control and stable production flow.
Key Features

Vertical design with 60 layers for high-capacity processing
8 heating modules (4×2) for uniform heat distribution
Temperature range: up to 200°C
High precision: ±1°C control, ≤±2°C uniformity
Fast throughput: minimum 35 seconds per PCB & pallet
Servo-driven lifting system for smooth and reliable operation
Optional Nitrogen (N₂) and cleanroom configuration

Capacity & Handling

Max PCB size: 300 × 250 mm
Product weight: up to 3 kg per layer
Component height: up to 25 mm
Inline entrance & exit conveyors
Manual or automatic rail width adjustment

Technical Specs

Dimensions: 1770 × 2030 × 2160 mm
Weight: ~1500 kg
Heating power: 48 KW (8 × 6 KW)
Conveyor height: 900 ± 30 mm

MSTECH Europe
Classic MTX-450
The MTX-450 Vertical Oven is a high-capacity thermal processing solution designed for larger PCBs, combining space-saving vertical design with precise temperature control and reliable automation.
Key Features

Vertical system with 60 layers for high throughput
8 heating modules (4×2) for consistent heat distribution
Temperature range: up to 200°C
High precision: ±1°C control, ≤±2°C uniformity
Fast cycle time: from 35 seconds per PCB & pallet
Servo-driven lifting system for smooth, accurate handling
Optional Nitrogen (N₂) and cleanroom configuration

Capacity & Handling

Max PCB size: 400 × 450 mm
Product weight: up to 3 kg per layer
Component height: up to 25 mm
Inline entrance & exit conveyors
Manual or automatic rail width adjustment

Technical Specs

Dimensions: 2200 × 2230 × 2160 mm
Weight: ~1800 kg
Heating power: 64 KW (8 × 8 KW)
Conveyor height: 900 ± 30 mm

MSTECH Europe
Classic MTX-650
The MTX-650 Vertical Oven is a high-capacity solution designed for large-format PCB processing, combining a space-saving vertical design with precise temperature control and high throughput performance.
Key Features

Vertical system with 60 layers for maximum productivity
8 heating modules (4×2) for uniform heat distribution
Temperature range: up to 200°C
High precision: ±1°C control, ≤±2°C temperature uniformity
Fast cycle time: from 35 seconds per PCB & pallet
Servo-driven lifting system for smooth, reliable operation
Optional Nitrogen (N₂) and cleanroom configuration

Capacity & Handling

Max PCB size: 600 × 650 mm
Product weight: up to 3 kg per layer
Component height: up to 25 mm
Inline entrance & exit conveyors
Manual or automatic rail width adjustment

Technical Specs

Dimensions: 3000 × 2460 × 2160 mm
Weight: ~2100 kg
Heating power: 72 KW (8 × 9 KW)
Conveyor height: 900 ± 30 mm

MSTECH Europe
MST- [SNAPCURE] UVA &UVC Multifrequence L
UV LED Curing System, Controller: PLC + HMI, With UVA sensor, With detection function( by voltage), 2 x Feane without glass Air Cooling,
Emitting window: 400x250mm, Wavelenght 254,365nm, 395nm
254nm：30mW/cm² (50mm)
365nm：300mW/cm² (50mm)
395nm：400mW/cm² (50mm)

MSTECH Europe
LITE PLUS [SNAP LIGHT] [SNAP FLIP]

MULTIFUNCTION LASER
WITH A UNIQUE EXTENDED
FOV, SUITABLE FOR
µMACHINING, SURFACE
PREPARATION, AND
DIGITAL SINTERING

The SNAP LIGHT module expands
the MSTECH software suite with a
high-precision laser system designed
for critical application in electronic &
semicon manufacturing. It performs
ultra- accurate ablation, marking,
sintering, cleaning, and edge-finishing
operations with full digital control.
SNAP LIGHT executes with
micrometric precision, ensuring
maximum efficiency, repeatability, and
reduced process errors.

Features
» Dimensions (WxDxH) : 900 x 1280 x 2148 mm
» INVERT PCBs (180º) FOR DOUBLE-SIDED PROCESS
» Laser spot: ≥ 40 μm.
» Marking area indicator.
» Internal barcode generator.
» Marca full graphics PC Software.
» Available as an OEM Kit or
within MSTECH Europe platform
compatible with SNAP MOTION, and
SMARTBOX and Process Tracker (optional)

MSTECH Europe
LITE 600 [SNAPACTIVE] Linear Atmospheric Plasma System

The MSTECH [SNAP ACTIVE] Linear Atmospheric Plasma System (LITE 600) is a compact, high-performance inline plasma solution designed to clean, activate, and prepare surfaces for advanced manufacturing processes.
Engineered for seamless integration into production lines, this system delivers uniform plasma treatment across wide surfaces, ensuring optimal adhesion, cleanliness, and process reliability.
Using advanced plasma technology, it effectively removes organic contaminants and modifies surface properties at low temperature, making it ideal for sensitive electronic and industrial applications.
With its compact footprint, reduced energy consumption, and real-time monitoring capabilities, the SNAP ACTIVE LITE 600 is the perfect solution for manufacturers looking to improve yield, quality, and process consistency.
👉 Ideal for high-precision industries such as electronics, semiconductor, automotive, and battery manufacturing.

Key Features

✅ Inline linear plasma system for continuous production
✅ Wide-area uniform plasma treatment
✅ Compact design (only 600 mm width) for easy integration
✅ Low-temperature plasma (<35°C) – safe for sensitive materials
✅ Advanced automatic power matching
✅ Real-time plasma intensity monitoring
✅ Built-in diagnostics: 12 failure alerts
✅ Digital interface for MES integration & traceability
✅ Energy-efficient (up to 25% power reduction)
✅ Compatible with multiple gases: N₂, O₂, Ar, CDA
✅CE
✅SEMI S2 / S8
✅ISO 7 Cleanroom (Class 10,000)

MSTECH Europe
MST-[SNAPCURE] UVA &UVC Multifrequence XL
UV LED Curing System, Controller: PLC + HMI, With UVA sensor, With detection function( by voltage), 2 x Feane without glass Air Cooling,
Emitting window: 500x400mm, Wavelenght 254,365nm, 395nm
254nm：30mW/cm² (50mm)
365nm：300mW/cm² (50mm)
395nm：400mW/cm² (50mm)

MSTECH Europe
MST-[SNAPCURE] UVA &UVC Multifrequence XXL

UV LED Curing System, Controller: PLC + HMI, With UVA sensor, With detection function( by voltage), 2 x Feane without glass Air Cooling,
Emitting window: 600x600mm, Wavelenght 254,365nm, 395nm
254nm：30mW/cm² (50mm)
365nm：300mW/cm² (50mm)
395nm：400mW/cm² (50mm)

MSTECH Europe
MST-[SNAPCURE] UVA Multifrequence L
UV LED Curing System, Controller: PLC + HMI, With UV sensor, With detection function( by voltage), 2 x Feane without glass Air Cooling,
Emitting window: 400x250mm, Wavelenght 365nm, 395nm
365nm：300mW/cm² (50mm)
395nm：400mW/cm² (50mm)

MSTECH Europe
MST-[SNAPCURE] UVA Multifrequence XL

UV LED Curing System, Controller: PLC + HMI, With UV sensor, With detection function( by voltage), 2 x Feane without glass Air Cooling,
Emitting window: 500x400mm, Wavelenght 365nm, 395nm
365nm：300mW/cm² (50mm)
395nm：400mW/cm² (50mm)
